Scalar types are the primitives of our schema and can hold a specific type of data. They are leaf types, meaning we cannot use e.g. { fieldName }
to further drill down into the type. The main purpose of a scalar is to define how a value is serialized and deserialized.
Besides basic scalars like String
and Int
, we can also create custom scalars like CreditCardNumber
or SocialSecurityNumber
. These custom scalars can greatly enhance the expressiveness of our schema and help new developers to get a grasp of our API.
GraphQL scalars
The GraphQL specification defines the following scalars.
String
type Product { description: String;}
This scalar represents an UTF-8 character sequence.
It is automatically inferred from the usage of the .NET string type.
Boolean
type Product { purchasable: Boolean;}
This scalar represents a Boolean value, which can be either true
or false
.
It is automatically inferred from the usage of the .NET bool type.
Int
type Product { quantity: Int;}
This scalar represents a signed 32-bit numeric non-fractional value.
It is automatically inferred from the usage of the .NET int type.
Float
type Product { price: Float;}
This scalar represents double-precision fractional values, as specified by IEEE 754.
It is automatically inferred from the usage of the .NET float or double type.
Note: We introduced a separate
Decimal
scalar to handledecimal
values.
ID
type Product { id: ID!;}
This scalar is used to facilitate technology-specific Ids, like int
, string
or Guid
.
It is not automatically inferred and the IdType
needs to be explicitly specified.
ID
values are always represented as a String in client-server communication, but can be coerced to their expected type on the server.
public class Product{ [GraphQLType(typeof(IdType))] public int Id { get; set; }}
public class Query{ public Product GetProduct([GraphQLType(typeof(IdType))] int id) { // Omitted code for brevity }}
Notice how our code uses int
for the Id
, but in a request / response it would be serialized as a string
. This allows us to switch the CLR type of our Id
, without affecting the schema and our clients.
GraphQL Community Scalars
The website https://www.graphql-scalars.com/ hosts specifications for GraphQL scalars defined by the community. The community scalars use the @specifiedBy
directive to point to the spec that is implemented.
scalar UUID @specifiedBy(url: "https://tools.ietf.org/html/rfc4122")
DateTime Type
A custom GraphQL scalar which represents an exact point in time. This point in time is specified by having an offset to UTC and does not use time zone.
The DateTime scalar is based on RFC 3339.
scalar DateTime @specifiedBy(url: "https://www.graphql-scalars.com/date-time/")
Note: The Hot Chocolate implementation diverges slightly from the DateTime Scalar specification, and allows fractional seconds of 0-7 digits, as opposed to exactly 3.
.NET Scalars
In addition to the scalars defined by the specification, Hot Chocolate also supports the following set of scalar types:
Type | Description |
---|---|
Byte | Byte |
ByteArray | Base64 encoded array of bytes |
Short | Signed 16-bit numeric non-fractional value |
Long | Signed 64-bit numeric non-fractional value |
Decimal | .NET Floating Point Type |
Url | Url |
Date | ISO-8601 date |
TimeSpan | ISO-8601 duration |
Uuid | GUID |
Any | This type can be anything, string, int, list or object, etc. |
Uuid Type
The Uuid
scalar supports the following serialization formats.
Specifier | Format |
---|---|
N | 00000000000000000000000000000000 |
D (default) | 00000000-0000-0000-0000-000000000000 |
B | {00000000-0000-0000-0000-000000000000} |
P | (00000000-0000-0000-0000-000000000000) |
X | {0x00000000,0x0000,0x0000,{0x00,0x00,0x00,0x00,0x00,0x00,0x00,0x00}} |
The UuidType
will always return the value in the specified format. In case it is used as an input type, it will first try to parse the result in the specified format. If the parsing does not succeed, it will try to parse the value in other formats.
To change the default format we have to register the UuidType
with the specifier on the schema:
builder.Services .AddGraphQLServer() .AddType(new UuidType('D'));
Any Type
The Any
scalar is a special type that can be compared to object
in C#.
Any
allows us to specify any literal or return any output type.
Consider the following type:
type Query { foo(bar: Any): String}
Since our field foo
specifies an argument bar
of type Any
all of the following queries would be valid:
{ a: foo(bar: 1) b: foo(bar: [1, 2, 3, 4, 5]) a: foo(bar: "abcdef") a: foo(bar: true) a: foo(bar: { a: "foo", b: { c: 1 } }) a: foo(bar: [{ a: "foo", b: { c: 1 } }, { a: "foo", b: { c: 1 } }])}
The same goes for the output side. Any
can return a structure of data although it is a scalar type.
If we want to access the data we can either fetch data as an object or you can ask the context to provide it as a specific object.
object foo = context.ArgumentValue<object>("bar");Foo foo = context.ArgumentValue<Foo>("bar");
We can also ask the context which kind the current argument is:
ValueKind kind = context.ArgumentKind("bar");
The value kind will tell us by which kind of literal the argument is represented.
An integer literal can still contain a long value and a float literal could be a decimal but it also could just be a float.
public enum ValueKind{ String, Integer, Float, Boolean, Enum, Object, Null}
If we want to access an object dynamically without serializing it to a strongly typed model we can get it as IReadOnlyDictionary<string, object>
or as ObjectValueNode
.
Lists can be accessed generically by getting them as IReadOnlyList<object>
or as ListValueNode
.
Additional Scalars
We also offer a separate package with scalars for more specific use cases.
To use these scalars we have to add the HotChocolate.Types.Scalars
package.
dotnet add package HotChocolate.Types.Scalars
HotChocolate.*
packages need to have the same version.Available Scalars:
Type | Description |
---|---|
EmailAddress | Email address, represented as UTF-8 character sequences, as defined in RFC5322 |
HexColor | HEX color code |
Hsl | CSS HSL color as defined here |
Hsla | CSS HSLA color as defined here |
IPv4 | IPv4 address as defined here |
IPv6 | IPv6 address as defined in RFC8064 |
Isbn | ISBN-10 or ISBN-13 number as defined here |
Latitude | Decimal degrees latitude number |
Longitude | Decimal degrees longitude number |
LocalCurrency | Currency string |
LocalDate | ISO date string, represented as UTF-8 character sequences yyyy-mm-dd, as defined in RFC3339 |
LocalTime | Local time string (i.e., with no associated timezone) in 24-hr HH:mm:ss |
MacAddress | IEEE 802 48-bit (MAC-48/EUI-48) and 64-bit (EUI-64) Mac addresses, represented as UTF-8 character sequences, as defined in RFC7042 and RFC7043 |
NegativeFloat | Double‐precision fractional value less than 0 |
NegativeInt | Signed 32-bit numeric non-fractional with a maximum of -1 |
NonEmptyString | Non empty textual data, represented as UTF‐8 character sequences with at least one character |
NonNegativeFloat | Double‐precision fractional value greater than or equal to 0 |
NonNegativeInt | Unsigned 32-bit numeric non-fractional value greater than or equal to 0 |
NonPositiveFloat | Double‐precision fractional value less than or equal to 0 |
NonPositiveInt | Signed 32-bit numeric non-fractional value less than or equal to 0 |
PhoneNumber | A value that conforms to the standard E.164 format as defined here |
PositiveInt | Signed 32‐bit numeric non‐fractional value of at least the value 1 |
PostalCode | Postal code |
Port | TCP port within the range of 0 to 65535 |
Rgb | CSS RGB color as defined here |
Rgba | CSS RGBA color as defined here |
SignedByte | Signed 8-bit numeric non‐fractional value greater than or equal to -127 and smaller than or equal to 128. |
UnsignedInt | Unsigned 32‐bit numeric non‐fractional value greater than or equal to 0 |
UnsignedLong | Unsigned 64‐bit numeric non‐fractional value greater than or equal to 0 |
UnsignedShort | Unsigned 16‐bit numeric non‐fractional value greater than or equal to 0 and smaller or equal to 65535. |
UtcOffset | A value of format ±hh:mm |
Most of these scalars are built on top of native .NET types. An Email Address for example is represented as a string
, but just returning a string
from our resolver would result in Hot Chocolate interpreting it as a StringType
. We need to explicitly specify that the returned type (string
) should be treated as an EmailAddressType
.
[GraphQLType(typeof(EmailAddressType))]public string GetEmail() => "[email protected]";
Learn more about explicitly specifying GraphQL types
NodaTime
We also offer a package specifically for NodaTime.
It can be installed like the following.
dotnet add package HotChocolate.Types.NodaTime
HotChocolate.*
packages need to have the same version.Available Scalars:
Type | Description | Example |
---|---|---|
DateTimeZone | A NodaTime DateTimeZone | "Europe/Rome" |
Duration | A NodaTime Duration | "-123:07:53:10.019" |
Instant | A NodaTime Instant | "2020-02-20T17:42:59Z" |
IsoDayOfWeek | A NodaTime IsoDayOfWeek | 7 |
LocalDate | A NodaTime LocalDate | "2020-12-25" |
LocalDateTime | A NodaTime LocalDateTime | "2020-12-25T13:46:78" |
LocalTime | A NodaTime LocalTime | "12:42:13.03101" |
OffsetDateTime | A NodaTime OffsetDateTime | "2020-12-25T13:46:78+02:35" |
OffsetDate | A NodaTime OffsetDate | "2020-12-25+02:35" |
OffsetTime | A NodaTime OffsetTime | "13:46:78+02:35" |
Offset | A NodeTime Offset | "+02:35" |
Period | A NodeTime Period | "P-3W3DT139t" |
ZonedDateTime | A NodaTime ZonedDateTime | "2020-12-31T19:40:13 Asia/Kathmandu +05:45" |
When returning a NodaTime type from one of our resolvers, for example a NodaTime.Duration
, we also need to explicitly register the corresponding scalar type. In the case of a NodaTime.Duration
this would be the DurationType
scalar.
public class Query{ public Duration GetDuration() => Duration.FromMinutes(3);}
builder.Services .AddGraphQLServer() .AddQueryType<Query>() .AddType<DurationType>();
This package was originally developed by @shoooe.
Binding behavior
Hot Chocolate binds most of the native .NET types automatically.
A System.String
is for example automatically mapped to a StringType
in the schema.
We can override these mappings by explicitly specifying type bindings.
builder.Services .AddGraphQLServer() .BindRuntimeType<string, StringType>();
Furthermore, we can also bind scalars to arrays or type structures:
builder.Services .AddGraphQLServer() .BindRuntimeType<byte[], ByteArrayType>();
Hot Chocolate only exposes the used scalars in the generated schema, keeping it simple and clean.
Custom Converters
We can reuse existing scalar types and bind them to different runtime types by specifying converters.
We could for example register converters between NodaTime's OffsetDateTime
and .NET's DateTimeOffset
to reuse the existing DateTimeType
.
public class Query{ public OffsetDateTime GetDateTime(OffsetDateTime offsetDateTime) { return offsetDateTime; }}
builder.Services .AddGraphQLServer() .AddQueryType<Query>() .BindRuntimeType<OffsetDateTime, DateTimeType>() .AddTypeConverter<OffsetDateTime, DateTimeOffset>( x => x.ToDateTimeOffset()) .AddTypeConverter<DateTimeOffset, OffsetDateTime>( x => OffsetDateTime.FromDateTimeOffset(x));
Scalar Options
Some scalars like TimeSpan
or Uuid
have options like their serialization format.
We can specify these options by registering the scalar explicitly.
builder.Services .AddGraphQLServer() .AddType(new UuidType('D'));
Custom Scalars
All scalars in Hot Chocolate are defined through a ScalarType
.
The easiest way to create a custom scalar is to extend ScalarType<TRuntimeType, TLiteral>
.
This base class already includes basic serialization and parsing logic.
public sealed class CreditCardNumberType : ScalarType<string, StringValueNode>{ private readonly ICreditCardValidator _validator;
// we can inject services that have been registered // with the DI container public CreditCardNumberType(ICreditCardValidator validator) : base("CreditCardNumber") { _validator = validator;
Description = "Represents a credit card number"; }
// is another StringValueNode an instance of this scalar protected override bool IsInstanceOfType(StringValueNode valueSyntax) => IsInstanceOfType(valueSyntax.Value);
// is another string .NET type an instance of this scalar protected override bool IsInstanceOfType(string runtimeValue) => _validator.ValidateCreditCard(runtimeValue);
public override IValueNode ParseResult(object? resultValue) => ParseValue(resultValue);
// define how a value node is parsed to the string .NET type protected override string ParseLiteral(StringValueNode valueSyntax) => valueSyntax.Value;
// define how the string .NET type is parsed to a value node protected override StringValueNode ParseValue(string runtimeValue) => new StringValueNode(runtimeValue);
public override bool TryDeserialize(object? resultValue, out object? runtimeValue) { runtimeValue = null;
if (resultValue is string s && _validator.ValidateCreditCard(s)) { runtimeValue = s; return true; }
return false; }
public override bool TrySerialize(object? runtimeValue, out object? resultValue) { resultValue = null;
if (runtimeValue is string s && _validator.ValidateCreditCard(s)) { resultValue = s; return true; }
return false; }}
By extending ScalarType
we have full control over serialization and parsing.
public class CreditCardNumberType : ScalarType{ private readonly ICreditCardValidator _validator;
public CreditCardNumberType(ICreditCardValidator validator) : base("CreditCardNumber") { _validator = validator;
Description = "Represents a credit card number"; }
// define which .NET type represents your type public override Type RuntimeType { get; } = typeof(string);
// define which value nodes this type can be parsed from public override bool IsInstanceOfType(IValueNode valueSyntax) { if (valueSyntax == null) { throw new ArgumentNullException(nameof(valueSyntax)); }
return valueSyntax is StringValueNode stringValueNode && _validator.ValidateCreditCard(stringValueNode.Value); }
// define how a value node is parsed to the native .NET type public override object ParseLiteral(IValueNode valueSyntax, bool withDefaults = true) { if (valueSyntax is StringValueNode stringLiteral && _validator.ValidateCreditCard(stringLiteral.Value)) { return stringLiteral.Value; }
throw new SerializationException( "The specified value has to be a credit card number in the format " + "XXXX XXXX XXXX XXXX", this); }
// define how the .NET type is parsed to a value node public override IValueNode ParseValue(object? runtimeValue) { if (runtimeValue is string s && _validator.ValidateCreditCard(s)) { return new StringValueNode(null, s, false); }
throw new SerializationException( "The specified value has to be a credit card number in the format " + "XXXX XXXX XXXX XXXX", this); }
public override IValueNode ParseResult(object? resultValue) { if (resultValue is string s && _validator.ValidateCreditCard(s)) { return new StringValueNode(null, s, false); }
throw new SerializationException( "The specified value has to be a credit card number in the format " + "XXXX XXXX XXXX XXXX", this); }
public override bool TrySerialize(object? runtimeValue, out object? resultValue) { resultValue = null;
if (runtimeValue is string s && _validator.ValidateCreditCard(s)) { resultValue = s; return true; }
return false; }
public override bool TryDeserialize(object? resultValue, out object? runtimeValue) { runtimeValue = null;
if (resultValue is string s && _validator.ValidateCreditCard(s)) { runtimeValue = s; return true; }
return false; }}
The implementation of Hot Chocolate's own scalars can be used as a reference for writing custom scalars.
